墙壁上安装的水平用途的轨道系统
H-RAIL ON WALL
可以用最小的视觉影响固定支座。
使用配备四个轮子的特定滑动装置,用户可以实现防坠落作业和悬挂作业。
可以安装在不同的基材(木材、混凝土和钢结构)上,以适应任何安装要求。
文件
技术数据表 | |
---|---|
符合性声明(DOC) | |
安全规程、安装和使用说明 | |
符合性声明(DOC) |
操作规程
操作手册 |
---|
RAIL
CODE | description | pcs. |
---|---|---|
RAIL3000 | 3m aluminium rail | 1 |
RAILVC90 | 90° aluminium vertical bend | 1 |
RAILVC135 | 135° aluminium vertical bend | 1 |
SUPPORT
CODE | description | pcs. |
---|---|---|
RAILBRAT | support element for rail | 1 |
RAILBRAT12 | M12 plate for RAILBRAT | 1 |
RAILBRATW | for fixing on wood | 1 |
RAILBRAS | for direct fixing on steel | 1 |
TERMINAL ELEMENT
CODE | description | pcs. |
---|---|---|
RAILEND | rail end-stop without exit | 1 |
RAILENDOPEN | rail end-stop with exit | 1 |
JOINT
CODE | description | pcs. |
---|---|---|
RAILJUN | junction for rails and bends | 1 |
SLIDING DEVICE
CODE | description | pcs. |
---|---|---|
RAILSLIDE | sliding device | 1 |
RAILSLIDEWALL | slide for wall application | 1 |
TOOL
CODE | description | pcs. |
---|---|---|
RAILJUNTOOL | template for rail junction holes | 1 |
RAILPLATE | Rail system ID plate | 1 |
FASTENING
CODE | description | pcs. |
---|---|---|
RAILOCKSCREW | Lock screw | 500 |
RAILSCREW | DIN 7991 A2-70 | 50 |
